| CPU |
 |
Socket 462 for AMD Athlon™ XP/ Athlon™/ Duron™ processor |
| |
FSB 266/200 MHz |
|
|
| |
CHIPSET |
| |
SiS® 740 & 962L |
| |
North Bridge: SiS® 740 |
| |
South Bridge: SiS® 962L |
|
|
| |
GRAPHICS |
| |
Integrated SiS® Real256 2D/3D Graphics |
| |
Share memory : 64MB |
|
|
| |
MEMORY |
| |
2 x 184-pin DDR DIMM socket support up to 2 GB |
| |
Support DDR266/200 DDR SDRAM |
|
|
| |
EXPANSION SLOT |
| |
2 x PCI slots |
| |
1 x CNR slot |
|
|
| |
STORAGE |
| |
Support by SiS® 962L |
 |
4 x Ultra DMA133/100/66 devices |
|
|
| |
AUDIO |
| |
C-Media CMI9738 4-channel audio CODEC |
| |
Compliant with AC'97 2.2 specification |
|
|
| |
LAN |
| |
VIA® VT6103 10/100 Mbps Fast Ethernet PHY |
|
|
| |
REAR PANEL I/O |
| |
1 x PS/2 keyboard & PS/2 mouse connectors |
| |
4 x USB ports |
| |
1 x RJ45 LAN connector |
| |
1 x VGA port |
| |
1 x Parallel port (LPT) |
| |
1 x Serial port (COM1) |
| |
1 x Audio port (Line-in, Line-out, Mic-in) |
|
|
| |
INTERNAL I/O CONNECTORS & HEADERS |
| |
1 x 20-pin ATX Power Supply Connector |
| |
1 x FDD connector supports two 360K~2.88MB FDDs |
| |
2 x IDE connectors |
| |
1 x Speaker header |
| |
1 x IrDA for SIR header |
| |
1 x USB card reader header |
| |
1 x USB 2.0 header support additional 2 USB ports |
| |
1 x Front panel switch/LED header |
| |
1 x Front panel audio header |
| |
CD in1/CD in2 header |
| |
CPUFAN/SYSFAN connectors |
|
|
| |
SYSTEM BIOS |
| |
Award BIOS with 2Mb Flash ROM |
| |
Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI |
| |
Supports ACPI revision 1.0 specification |
|
|
| |
FORM FACTOR & LAYERS |
| |
Micro-ATX (244mm*190mm), 4 Layers |
|
|
)
